Quick Overview
Features:-
- UL Standard 758 - Styles 1007, 1569, & 1581
- UL AWM Style 1007 (80°C)/1569 (105°C)
- UL AWM Style 1061 (80°C)
- MIL-W-16878/2 Type C (105°C)
- CSA AWM I A/B (80°C/105°C)
- MIL-W-16878/1 Type B (80°C)
- CSA Type SR-PVC (80°C)
- CSA TR64 (90°C)
Interested in this item or want more information?
Hours:
Phone: 800-613-3873
Email: info@aaatool.net
Can't find what you want? Give us a call and we can help you find it.
Details
PRODUCT SPECIFICATION :-
| Parent Number | F12035- | | Description |
12 65/30 TC AWM 1569 or 1581 AWM I A/B | | Diameter | 0.123
| | Stranding | 65/30 TC LHL | | | Tolerance± | 0.003
| |
| Style | UL: AWM 1569 or 1581 CSA: AWM I A/B |
| Insulation | PVC |
| Print Legend | 12 AWG (3.31mm2) E96824 (PLANT ID CODE) (AWM LOGO) AWM 1569 105C OR 1581 80C 300V VW-1--- 156016 CSA AWM I A/B 105C 300V FT1 |
| Voltage | 300V |
| Temperature
| 1569=105C, 1581=80C |
Additional Information
Manufacturer: Coleman Cable - CCI
For More Information on the TC AWM 1569,
[Click Here] to Link to Manufacturer Web Site
