22/6 STRANDED BC CMP/CL3P

Coleman Cable - CCI

SKU / Product Info	Quantity
72306 22/6

Features & Applications :-

Low Smoke PVC jacket
Ripcord and Sequential Footage Marking
Temperature Rating of 75°C
Power limited circuit and communication cable for use in plenum applications
Remote Control, Signaling, Security Systems, Communications, Intercom/P.A. Systems, Sound/Audio, and Nurse Call

Hours: 6am - 5pm

Phone: 800-613-3873

Email: info@aaatool.net

Can't find what you want? Give us a call and we can help you find it.

Construction Parameters

Electrical Properties :

Conductor	22 AWG Bare Copper
Stranding	7/30
Insulation Material	Low Smoke PVC
Insulation Thickness	0.006'' Nom
Insulated Conductor Dimensions	0.041'' Nom.
Number of Conductors	6
Lay Length(Pairs)	5.00'' Nom.
Jacket Material	Low Smoke PVC
Jacket Thickness	0.014'' Nom.
Overall Cable Diameter	0.151'' Nom
Approximate Cable Weight	21.6 Lbs/1M' Nom.
Flame Rating	NFPA 262 Steiner Tunnel Smoke and Flame Test

Temperature Rating	-20°C to 75°C
Rated Voltage	300 V Max per NEC Article 800
Capacitance Between Conductors @ 1 KHZ	31 pF/ft Nom.
Capacitance Between Conductors to Shield @ 1 KHz	----
DC Resistance per Conductor @ 20°C	16.90 Ohms/1M' Nom.

Manufacturer: Coleman Cable - CCI

For More Information on the 22/6 STRANDED BC CMP/CL3P , [Click Here] to Link to Manufacturer Web Site
