STRANDED BC TFFN

Coleman Cable - CCI

SKU / Product Info	Quantity
51011 18 AWG
51012 16 AWG

Features & Applications:-

Hours: 6am - 5pm

Phone: 800-613-3873

Email: info@aaatool.net

Can't find what you want? Give us a call and we can help you find it.

Construction Parameters :-

Electrical & Environmental Properties :-


Conductor	18 AWG Bare Copper
Stranding	16/30
Insulation Material	PVC/Nylon
Insulation Thickness	0.016'' Nom.
Nylon Insulation Thickness	0.005'' Nom.
Insulated Conductor Diameter	0.088'' Nom.
Approximate Cable Weight	7.4 Lbs/1M' Nom.


Temperature Rating	-20°C to 90°C
Operating Voltage	600 V RMS Max,1000V (AWM 1452)
DC Resistance per Conductor @ 20°C	6.49 Ohms/1M', Nom.

Manufacturer: Coleman Cable - CCI

For More Information on the STRANDED BC TFFN, [Click Here] to Link to Manufacturer Web Site
