Quick Overview
FEATURES :-
- Manufactured with advanced synthetic rubber compounds
- -40°C to 90°C temperature extremes
- Exceptional flexibility
- Excellent resistance to flame, deformation, ozone, oils, acids and chemicals
- Oil resistant insulation and jacket
- Abrasion resistant
- Flexible in cold temperatures
Interested in this item or want more information?
Hours:
Phone: 800-613-3873
Email: info@aaatool.net
Can't find what you want? Give us a call and we can help you find it.
Details
Applications:-
- Motor leads, portable lights, battery chargers, portable stage lights and portable machinery
- National Electric Code Article 400 applications
Industry Approvals:-
- MSHA approved for flame resistance in mining applications
- CSA certified
- ROHS Compliant
| Part Number | AWG | No. Cond. | Stranding | Insulation Wall, Nom. | O.D., Nom. | Net Weight | Amps* | Nom. DCR ?/1M' | Color Rotation |
| Inches | mm | Inches | mm | lb./kft. | kg/km |
| 822220 | 8 | 2 | 133/0.0106 | 0.050 | 1.27 | 0.632 | 16.05 | 274 | 408 | 40 | 0.72 | Black, White |
Additional Information
Manufacturer: Coleman Cable - CCI
For More Information on the SOOW ROYAL ROHS NON-UL,
[Click Here] to Link to Manufacturer Web Site
